Pipe & Fittings


Laybond's Fiberglass pipes are designed to meet or exceed a multitude of plant specifications and various pressure ratings as well as industry accepted standards.

Quality Fiberglass pipe requires extensive experience, knowledge and training working with resin complexities. Laybond can virtually source any resin required for your application, and has produced pipes for world class companies like Coca-Cola for over 23 years. We manufacture, fabricate and install FRP pipe from 25 mm to 1500nmm as well as a complete line of fittings.

PIPING APPLICATIONS

Laybond provide complete Fiberglass piping systems for a variety of applications, designed and manufactured to the highest quality standards. Laybond also assist customers with site layout, anchoring, support spacing, flow rate design, material selection and installation procedures.





MOTOR FUEL UNDERGROUND PIPING

This is used for the underground transfer of petroleum products, alcohol and alcohol-blended gasoline motor fuels. This underground piping is available in diameters of 50 mm to 150 mm inches.

MUNICIPAL, CHEMICAL AND INDUSTRIAL PIPING

Standard and custom fiberglass above ground and underground piping is used for municipal, chemical, and industrial applications including transmission of acids, caustics and solvents, and for cooling tower lines, fire protection systems, waste water treatment process lines, raw water inlet and discharge lines. Pipe jacking, slip lining and micro tunnelling no-dig applications are also included. Pipe diameters range from 25 mm to 1500 mm.

FEATURES

Performance Tested
Leak-Free Joints
Low Maintenance

Laybond has manufactured its Products using a wide variety of existing resin materials to meet our customers exacting specifications. Our current thermoset resin systems include Polyester, Bisphenol and Vinyl Ester. Where FRP will not work, dual laminate Products can, in many instances, serve well.

Dual laminate is a hybrid system made of FRP structure outside and specialized thermoplastic liner inside. The liner is matched to specific chemical requirements to optimize longevity including the ability to withstand high temperature requirements and abrasion resistance.

Dual laminated Tanks and Equipments are manufactured with a durable fibreglass composite matrix exterior for mechanical strength. The corrosion resistant thermoplastic interior offers exceptional service against dangerous and hazardous chemistry. It offers superior resistance to leaching agents, chemical attack as well as high purity process capabilities.

Dual Laminate

Liner Options
